Hitze
Hitze - Ardente Duo
Hitze - Ardente Duo
Regular price
€4.485,00 EUR
Regular price
Sale price
€4.485,00 EUR
Unit price
/
per
Taxes included.
Couldn't load pickup availability
- Deep combustion chamber.
- A new type of guillotine.
- Increased mass for greater heat accumulation.
- Fireplace insert suitable for recuperation.
| 90x41 | 105x43 | 120x43 | |
| Energy class: | A | >> | >> |
| Ecodesign | + | >> | >> |
| BlmSchV II | + | >> | >> |
| Nominal power (kW) | 18 | 20 | 22 |
| Heating load range [kW] | 9-23 | 10-26 | 11-28,5 |
| Thermal efficiency [%] | 79 | 78 | 76,5 |
| Pollen emissions at 13% O2 (g/m³) | 0,035 | 0,036 | 0,036 |
| CO emissions at 13% O2 (g/m³) | 0,584 | 0,508 | 0,431 |
| Weight (kg) | 350 | 395 | 421 |
| Flue diameter [mm] | 200 | >> | >> |
| Inlet diameter [mm] | 125 | >> | >> |
| Active area of outlet grilles (cm²) | 1260-1440 | 1400-1600 | 1540-1760 |
| Active area of inlet grilles (cm²) | 720-1170 | 800-1300 | 880-1430 |
| Glass measurements | 900 x 410 | 1050x430 | 1200 x 430 |
| Measurements (mm) | 1192 x 1554 x 694 | 1324 x 1604 x 708 | 1474 x 1604 x 708 |
