Hitze
Hitze - Cubo 8,5kW / 9,5kW
Hitze - Cubo 8,5kW / 9,5kW
Regular price
€1.656,00 EUR
Regular price
Sale price
€1.656,00 EUR
Unit price
/
per
Taxes included.
Couldn't load pickup availability
- An ideal choice for installations that use open hearths.
- Allows to significantly reduce the size of the fireplace housing.
- The fan cassette does not require the installation of fireplace grilles.
- Fireplace insert suitable for recuperation.
| CUBO 700 | CUBO 800 | |
| Energy class: | A+ | A+ |
| Ecodesign | + | + |
| BlmSchV II | + | + |
| Nominal power (kW) | 8,5 | 9,5 |
| Heating load range [kW] | 4-10 | 4,5-12 |
| Thermal efficiency [%] | 87 | 88 |
| Pollen emissions at 13% O2 (g/m³) | 0,025 | 0,025 |
| CO emissions at 13% O2 (g/m³) | 1,002 | 1,159 |
| Material | P265GH boiler steel grade according to EN 10028-2 | >> |
| Weight (kg) | 127 | 127 |
| Flue diameter [mm] | 150 | 150 |
| Inlet diameter [mm] | 100 | 100 |
| Measurements (mm) | 700x540x470 | 800x540x470 |
| Fuel type | seasoned hardwood (beech, birch, hornbeam) with a moisture content of 12-20% | >> |
| Maximum length of billets (mm) | 350 | 400 |
