T-90 Right Corner, 25kW

TECHNICAL SPECIFICATIONS:
– Double-walled fireplace made of 4mm steel.
– High-resistance ceramic glass (4mm) by the German company SCHOTT, resistant to temperatures up to 750°C.
– Telescopic door guides featuring the latest technology by the German company SCHOCK.
– Internal lining made of removable cast iron plates.
– Door locking mechanism for enhanced safety.

External Dimensions (cm) (Height, Width, Depth): 186 x 106 x 60
Internal Dimensions (cm) (Height, Width, Depth): 49 x 90 x 44
Door Opening Dimensions (cm) (Height, Width, Depth): 34 x 87.5 x 39.5
Weight (kg): 314
Chimney Diameter (mm): Φ250
Number of Hot Air Outlets (Φ125): 2+2 (optional)
Firebox Lining: Cast iron
Total Heat Output (kW/h): 25.0
CO Emissions (13% O2): 0.1380 (<1)
Efficiency (%): 72.5
Primary Air: YES
Secondary Air: YES
Tertiary Air: YES
Hourly Wood Consumption (kg/h): 7.20 – 7.25
